T4H Series single-seat control valves
Product Description
Overview
T4H Series single-seat control valve can be used to control various pressure and temperature fluids. The valve body is S streamlined channel with small pressure drop loss, large flow, wide adjustable range, high flow characteristic accuracy, and multi-spring type. The film actuator is used together, with compact structure and large output force.
| Valve Series | T4H | ||
| Pressure rating | 1.6Mpa~10Mpa | ||
| Size range | DN15~DN300 | ||
| TemperatureºC | -100~+450 | ||
| Materials | Carbon steel、 stainless steel | ||
| Connection Type | Flange，welding | ||
| Standards | GB、ANSI、JB | ||
| Sample No. | T4H01 | ||
